High efficiency | High Stability |
CAN-Bus technology reduces maintenance and increase overall performance | Low battery protection prolongs the usable life of battery |
100% AC system ensures high performance and stability, easy operation and maintenance | Low center of gravity ensures vehicle operation more stable |
Advanced control system reduces failure rate,increasing work efficiency | Reliable hydraulic system ensures smooth stacking shelves with goods |
High Safety | Easy maintenance |
Emergency button switch makes more satety and reliability during operation | AC Motor reduces replacement of Carbon brush |
New design of mast structure provides a wide operation view | Multi-LCD digital display provides fast and accurate monitoring vehicle status |
Regenerative braking reduces power consumption and extends battery working time |
Model | CPD16 | CPD20 | CPD20A | CPD25 | ||
Drive |
Electric |
|||||
Load capacity/rated load |
Q(kg) |
1600 |
2000 |
2000 |
2500 |
|
Load centre distance |
C(mm) |
500 |
||||
Lift height |
h3(mm) |
3000 |
||||
Free lift |
h2(mm) |
135 |
140 |
140 |
||
Mast/fork carriage tilt forward/backward |
α/β(*) |
6°/12° |
||||
Lowered mast height |
h1(mm) |
2025 |
2045 |
|||
Overhead load guard(cab) height |
h5(mm) |
2178 |
2205 |
|||
Ground clearance,centre of wheelbase |
m1(mm) |
110 |
110 |
|||
Length to face of forks |
I2(mm) |
2182 |
2418 |
|||
Overall width |
b1(mm) |
1080 |
1150 |
|||
Fork dimensions |
s/e/l(mm) |
35x100x920 |
40x122x1070 |
40x122x1070 |
||
Fork width |
mm |
200-970 |
250-970 |
250-1040 |
||
Load distance,centre of drive axle to fork |
x(mm) |
399 |
404 |
478 |
||
Turning radius |
Wa(mm) |
2050 |
2130 |
|||
Extended mast height |
h4mm |
4008 |
4145 |
|||
(1000×1200 crosswise) |
Ast(mm) |
3905 |
3910 |
4110 |
||
(800×1200 lengthwise) |
Ast(mm) |
3945 |
3950 |
4150 |
||
Travel speed(laden) |
km/h |
12 |
12.5 |
|||
Travel speed(unladen) |
km/h |
13 |
13.5 |
|||
Lift speed(laden) |
mm/s |
370 |
225 |
|||
Lift speed(unladen) |
mm/s |
525 |
400 |
|||
Max gradient performance(laden) |
% |
15 |
15 |
|||
Max gradient performance(unladen) |
% |
15 |
15 |
|||
Service brake |
hydr. |
|||||
Tyre size,front |
6.50-10-1 OPR |
7.00-12-12PR |
||||
Tyre size,rear |
5.00-S-8PR |
18x7-8-14PR |
||||
Service weight (incl.battery) |
kg |
3050 |
3240 |
3920 |
4120 |
|
Drive motor |
kw |
7.5 |
7.5 |
11 |
||
Lift motor |
kw |
10 |
10 |
9.5 |
||
Battery voltage,nominal capacity k5 |
V/Ah |
48/400 |
48/450 |
48/560 |
||
Type of drive control |
AC |
|||||
Manufacturer of drive control |
ZAPI |
|||||
Operating pressure for attachments | Mpa |
17.5 |
